Marshall Mini Stack Schematics
The Mini Stack concept was introduced in 1984. The Mini Stack cabinets were smaller 4×10″ or 2×12″ versions of the normal 4×12″ cabinets. The heads were downsized accordingly to fit.
2204S, 50W head
The 2204S was introduced in 1986 and discontinued in 1987. It was the same amp as the JCM800 2204 but fitted in a smaller cabinet to match the mini stack size.
Schematic of the 2204 pre amp with 2x ECC83 (Marshall, 1988).
Schematic of the 2204 power amp and PSU with 1x ECC83 & 2x EL34 (Marshall, 1988).
3203 Artist, 30W head
The 3203 Artist was introduced in 1984 and discontinued in 1991. The 4203 is the combo version of the 3203 head. Don’t confuse this amp with the older Artiste amps from the 1970s. The preamp is solid state, only the power amp uses tubes.
User manual for Split Channel models: 2205, 2210, 3203, 3210, 4203, 4210, 4211, 4212, 5210, 5212, 5213, 5215 & 5275.
Schematic of the pre amp schematic (solid state), 3203CT Issue 2 (Marshall, 1986).
Schematic of the power amp & PSU with 1x ECC83 & 2x EL34, JM100CT Issue 2 (Marshall, 1986).
Photograph of a 3203 head. Thanx to Christoph Arndt.
3210 Lead 100 MOSFET, 100W head
The 3210 Lead 100 MOSFET head was introduced in 1984 and discontinued in 1991. It is capable of delivering 100W in a 4Ω load.
User manual for Split Channel models: 2205, 2210, 3203, 3210, 4203, 4210, 4211, 4212, 5210, 5212, 5213, 5215 & 5275.
Schematic with the famous Hitachi 2SK134 and 2SJ49 MOSFETs, Issue 2 (Marshall, 1986).
Schematic with the famous Hitachi 2SK134 and 2SJ49 MOSFETs, Issue 7 (Marshall, 1990).
Photograph of a 3210 mini stack.
1965A, 4×10″ 8Ω Mini Stack Cabinet, angled front.
These mini stack cabinets were introduced in 1984 and discontinued in 1991. They were fitted with four 10″ Celestion G10L35 8Ω speakers.
1965B, 4×10″ 8Ω Mini Stack Cabinet, straight front.
These mini stack cabinets were introduced in 1984 and discontinued in 1991. They were fitted with four 10″ Celestion G10L35 8Ω speakers.
1966A, 2×12″ 8Ω Mini Stack Cabinet, angled front.
These mini stack cabinets were introduced in 1984 and discontinued in 1991. They were fitted with two 12″ Celestion G12T-75 16Ω speakers.
1966B, 2×12″ 8Ω Mini Stack Cabinet, straight front.
These mini stack cabinets were introduced in 1984 and discontinued in 1991. They were fitted with two 12″ Celestion G12T-75 16Ω speakers.
